| 40ft苹果舱移动房配置清单 40ft Apple Cabin Configuration List | ||||||
| A | 尺寸 Specification | 11500*2200*2450mm | =DISPIMG("ID_A91F0AC81A444FA8B34C6ED422C2CF0E",1) | |||
| B | 架构 | 部分 Part | 描述 Description | 图片 picture | ||
| C | 1.框架（Q235镀锌方管) Frame（Q235 Galvanized square tube） | 主框架 Main frame | 100mm*100mm*2.5mm |  | ||
| 墙面 Wall | 40mm*60mm*1.2mm、角柱斜拉加强 Corner column diagonal reinforcement | |||||
| 底面 Bottom | 40mm*60mm*1.2mm、横向间距不低于400mm Horizontal spacing not less than 400mm | |||||
| 顶面 Top | 40mm*80mm*1.5mm | |||||
| 油漆 Paint | 环氧富锌底漆+专用面漆 Epoxy zinc-rich primer + special topcoat | |||||
| 2.地面 Ground | 基板：18mm高密度水泥压力板 Substrate: 18mm high-density cement pressure plate | =DISPIMG("ID_68A9FEBD7B494F0C98FC32E06C1350FE",1) | ||||
| 地板：10mm复合木地板、搭配踢脚线(颜色可选） Floor:10mm composite wood flooring with skirting line（colour optional） | =DISPIMG("ID_5C557C6F44F44756AF905D0BCBF5059A",1) | |||||
| 3.墙面 Wall | 外墙 Exterior wall | 1.5mm镀锌板/（颜色可选） 1.5mm galvanized panel (optional) | =DISPIMG("ID_0114003295484C148CE0E6193CED1FDC",1) | |||
| 3.墙面 Metope | 内墙 Interior wall | 8mm碳晶板（颜色可选） 8mm Carbon crystal plate(colour optional) | =DISPIMG("ID_66C78DD805474026BCBD31C82ADA1FDE",1) | |||
| 外墙胶、内墙胶、内墙阴角线 External wall adhesive, internal wall adhesive, and internal wall corner lines | =DISPIMG("ID_50F021AEAF8944E087ABC717E9A5ACFA",1) | |||||
| 4.屋顶 Roof | 外屋顶 Outer roof | 0.8mm瓦楞板（满焊工艺、耐候结构胶、贴防水胶带） 10mm corrugated board (full welding process, weather resistant structural sealant, and waterproof tape) | =DISPIMG("ID_2C03F6DD475444E985637C92F43506F2",1) | |||
| 内屋顶 Inner roof | 8mm碳晶板 8mm Carbon crystal plate | =DISPIMG("ID_D0F12A43A0EF4AAE90C86803DF331610",1) | ||||
| 5.保温 Thermal insulation | 50mm聚氨酯（可做加厚） 50mm polyurethane (can be thickened) | =DISPIMG("ID_4C97D1FD46E94572A736B9A0EC17C5A0",1) | ||||
| 6.门窗 Doors and windows | 入户门 Entrance door | 2200mm*1000mm断桥铝门 Insulated aluminium door | =DISPIMG("ID_A3D3563E2BC54B508B826162C54D87E4",1) | |||
| 窗户 Window | 800mm*1000mm断桥铝窗*3 Insulated aluminium window*3 | =DISPIMG("ID_B17B38EA90454C8F9435D1D8BE56B3E6",1) | ||||
| 7.玻璃 glass | 5+12+5双层中空钢化玻璃（福特蓝镀膜） 5+12+5 hollow tempered glass | =DISPIMG("ID_6E856BE5D0884E8884F20C7B6AEB9126",1) | ||||
| 8.总控 Electric control | 漏电保护 Leakage protection | 断路器断电保护 Circuit breaker power-off protection | =DISPIMG("ID_ABB04EFFB2754EDD810757EDEE57D74C",1) | |||
| 内部线路 Internal Wiring | 主线6平方、配空调插口 Main line 6 square milimeters, equipped with 16A socket | =DISPIMG("ID_7EE96BE8A7134F8DBA00787F74E1139B",1) | ||||
| 插座 socket | 澳新标准 Australia and New Zealand Standards | =DISPIMG("ID_0285DF742BA944D7A95B968E2D71FA24",1) | ||||
| 灯具 lamps and lanterns | LED圆形吸顶灯 LED ceiling lights | =DISPIMG("ID_E71DF9EF73CF40A286B1E64F39C9EACB",1) | ||||
| D | 9.卧室*2 bedroom*2 | 卧室门*2 bedroom door*2 | 2000mm*600mm钛镁合金门*2 Titanium-magnesium alloy doors*2 | =DISPIMG("ID_4AC85A3F81EF43A98E602BEB8F8E39C7",1) | ||
| E | 10.洗手间 Washroom | 马桶 toilet | 品牌马桶 new Branded toilet | |||
| 洗手盆 Wash basin | 陶瓷盆含镜子 Ceramic basin with mirror | |||||
| 花洒 Shower set | 三合一独立花洒 3 in 1 shower set | |||||
| 浴霸 bath heater | 热风、排风式浴霸 Hot air and exhaust shower heater | |||||
| 热水器 water heater | 新飞品牌 Xinfei brand | =DISPIMG("ID_75C0B25405EE4209930CDBF7B217E4AA",1) | ||||
| 浴室门 bathroom | 2000mm*600mm钛镁合金门 Titanium-magnesium alloy doors | =DISPIMG("ID_4AC85A3F81EF43A98E602BEB8F8E39C7",1) | ||||
| F | 11.厨房Kitchen | 橱柜 cupboard | 1500*550*800mm底柜+1500*4400*700mm吊柜，含水槽和电磁炉 1500*550*800mm base cabinet + 1500*4400*700mm wall cabinet, including sink and induction cooker | =DISPIMG("ID_6CE2273051894B77BEBBA20798350793",1) | ||
| FOB Qingdao Price: 12550USD/unit | ||||||
